OptiSpot R Cover- Diffusor plate
Article number:
35.908.1001-1
EAN:
4049853
Product information "OptiSpot R Cover- Diffusor plate"
For use with reflectorsn 35.850.1001 - 1004 with Ø 110 mm
The following product properties are achieved by combining a reflector with a cover plate :
• Soft transition of the color fringes
• Possibly visually disruptive openings of the connector are covered
• Dust proof
• Insect protection • Contact protection (reflector)
| Color: | diffus |
|---|---|
| Height: | 1,7 mm |
| Light Distribution: | Wider light diffusion |
| Material: | PC, satined surface, clearPC, satined surface |
| Note warranty conditions: | *Warranty conditions of BJB GmbH & Co. KG as stated as available via the Internet under https://www.bjb.com/en/legal-information/general-terms-and-conditions/ are valid. |
| Operating temperature: | max. 100 °C |
| Packaging quantity: | 108 |
| Producttype: | OptiSpot Reflectors Ø 110 mm |
| Series: | Reflectors Ø 110 mm for Spotlight Connectors Ø 50 mm |
| Weight: | 4,2 g |
| mounting method 1: | Snap in fixing onto top side of the reflector by means ofsnap in hooks |
| old article number: | 35.908.1001.89 |
